Huixian Xinda Textile Machinery Parts Co., Ltd. provides 120# Denting Hook Loom Preparation Tool,reed insertion knives - wooden handle reed dressing knives - weaving machine preparation equipment. The reed insertion knives come in various specifications, with sizes ranging from 40# to 120#, progressively decreasing in thickness. The blade thickness of the 120# Denting Hook is 0.23mm, the face width at the alternating reed guiding position is 12.6mm, and the diameter at the front of the wooden handle is 19.2mm. Reed insertion knives, textile tools, reed dressing tools, and weaving equipment fall under the category of textile hardware tools and are also manual reed insertion tools.

The packaging of the wooden handle inserted denting hook is 1 piece/bag, and the hanging position is circular hole shaped (inner diameter is 3.5mm), which is slightly different from the common reed blade holes in China. The diamond shaped riveting block fits tightly with the outer diamond shaped hole, and the denting hook will not swing left and right.

The above picture shows the appearance of the 120 gauge denting hook after disassembly. The black denting hook has good toughness, wear resistance, and is not easily deformed; The total length of the reed blade is 239mm, the total length of the wooden handle is 70.5mm, and the diameter of the circular hoop cap is 14.6mm.

The circular concave hole of the reed blade is 49mm away from the metal hoop cap, and the width of the right angle hook used for hanging at the front of the reed blade is 4.5mm. The range of use of the textile tool - reed blade:

For steel reeds with a density below 8D/CM, use 40 #; for steel reeds between 8-12D/CM, use 60 # (with a blade thickness of 0.45mm); for steel reeds between 12-20D/CM, use 80 # (with a blade thickness of 0.3mm); for steel reeds above 20D/CM, use 120 # (with a blade thickness of 0.2-0.23mm),

Explanation: The parameters of the reed blades from different manufacturers may vary, and the above are for reference only.

The minimum order quantity for 120 # Reed Insertion Knife(denting hook), Wooden Handle Reed Removal Knife, and Weaving Machine Preparation Equipment is 1 piece. If you need to purchase products such as 40 # Reed Insertion Knife, 60 # Reed Knife, 80 # Reed Removal Tool, and Weaving Equipment, please contact Mr. Yang from our company for consultation.
