Huixian Xinda Textile Machinery Parts Co., Ltd. supplies A39 Bush Front Tongue Outer Bracket Sleeve, A39 Bush,Front Tongue,Bracket,Loom Parts, bearing bushes for the front flange plate inner and outer side supports of weaving machines. The material of the weaving machine bushing A39 is powder metallurgy, with dimensional specifications: outer diameter of 16mm, inner hole diameter of 12mm, straight cylinder length of 14mm, and a quantity of 2 pieces per weaving machine.

The out end bracket(support foot) of the K00-2 front tongue(convex edge plate) and the inner wall of the in side support foot of the K00-3 convex edge plate (used for both 3300-1/1515 models and GA611-2103 bushings for 2100-1/GA615 models) each use one A39 bushing, which is a replacement device accessory.

Use a shuttle to calibrate the front and rear positions of K00-3 and K00-2 inside and outside, with the inner side being 3 millimeters wider than the shuttle and the outer side being 1.6 millimeters wider than the shuttle. The A39 lining for the support foot of the weaving machine convex edge board is a commonly used accessory. Powder metallurgy lining(Bush),Front Tongue,Bracket,Loom Parts, During actual installation, please place a wooden board on it and use a hammer to hit it into the inner cavity of the support foot.

The packaging of A39 convex edge plate support feet with liners is shown in the above picture, with 20 pieces per bag; If you need to purchase textile bushings, 1511 loom bushings, 1515 loom bushings, shuttle box convex edge plates, shuttle loom support feet and other loom accessories, you can contact Mr. Yang from our company for consultation.
